Outstanding Features
1: Install both main rubber roller and grind roller to drive the materials efficiently.
Adopts Maglev printing technologies based on heavy duty machine body design to achieve high speed up to 200sqm and smooth movement for accurate ink drops placement.
2: Advanced control technologies including superior feathering processing and nozzles compensation for fast and excellent printing output.
3: Revolutionary uv curing system to have glossy and matte printing result for indoor and outdoor applications. Low cost uv inks to replace solvent inks for evironment-friendly applications and longer outdoor durability more than 12 months.
4: Versatile functions including dual roll media printing, stiff materials pre-warming, adjustable vacuum suction and optional with automatic media width measurement and knives cutting.
Specification Data
|
Model |
Spirit 3200 RtR |
|||
|
Print Size |
3200mm |
|||
|
Table Type |
Water cooling with Vacuum Suction |
|||
|
Media Thickness |
0.18-2.0mm |
|||
|
P.H. Type |
Konica1024A |
|||
|
Number Of P.H. |
8,10,12,15,16,18,24 |
|||
|
Print Speed 3/4Rows |
Draft mode |
135m2/h |
Draft mode |
180m2/h |
|
Production Mode |
90m2/h |
Production Mode |
120m2/h |
|
|
Quality mode |
55m2/h |
Quality mode |
70m2/h |
|
|
Colors Configuration |
3(CMYK)+WW; 3(CMYK); 3(CMYK Lc Lm); 4(CMYK); 4(CMYK Lc Lm) |
|||
|
Rip Software |
Caldera, Photoprint |
|||
|
Power Condition |
Single Phase AC 220V, 7KW |
|||
|
Net Weight |
2200Kgs |
|||
|
Dimension |
5800x1500x1700mm |
|||
Multiple Printheads Configuration
Applications
Details
